PA050
.JPG)
PA050
PA series products are designed as middle-size and middle-travel-range precise motorized stages. The base of this series employ high-rigidity U-type structure to ensure this stage could be suitable for the operations in the circumstances of heavy load, high rigidity and multi-dimension combinations. A stainless-steel dust proof cover is optional to protect all inner parts of stages from particles and dust in real operation environments, which could guarantee better stability, durability and the capability to keep a long-term accuracy. PA series products equip precision ball screw, linear-slider guide and high-performance shaft coupling units. This kind of design offers good adaptabilities for being used in accurate operation scenarios with relative complex environments.
MODEL: PA050
Specifications
Travel range(mm)
50
Stage surface size(mm)
120×120
Transmission mechanism
precision ball screw,Φ12×4
Guide mechanism
linear-slider guides
Main body material and surface
Black anodized aluminum alloy
Weight(Kg)
5.8
Shaft coupling (OD - OD1- OD2)
(mm)
30-6.35-8
Step resolution(µm)
20
20-fine-subdivision resolution
(µm)
1
Max speed(mm/s)
40
Single-direction positioning
accuracy
≤30
Repositioning accuracy (um)
≤±3
Backlash(µm)
≤3
Backlash(um)
≤5
Static parallelism (mm)
≤0.1
Motion straightness(µm)
≤20
Motion parallelism(µm)
≤25
Yaw(”)
≤50
Pitch(”)
≤55
Motor and its stepping angle (°)
Two-phase 57 stepping motor, 1.8
Brand and model number of motor
Shinano，SST59D3206
Working current(A)
2.8
Holding torque of motor (N·m)
1.44
Brand and model number of
stepping driver (optional)
Moons, SR4
Type of plug for stage
DB9(pin)
Type of cable for stage
High flexibility cable (Helukabel, Germany)
Length of connection cable(m)
0.2
Position-limit sensors (built-in)
2*PM-L25 (SUNX, Japan)
Origin-point sensors (built-in)
1*PM-L25 (SUNX, Japan)
Voltage of power supply for
sensors (V)
DC5~24V±10%
Current consumption(mA)
<60 (total)
Control output
NPN open collector output DC5～24V 8mA or
less Residual voltage 0.3V or less (when load current is 2mA)
Status of output ports
Position limit sensor: output ON when sensor is blocked;Origin-point sensor: output OFF
when sensor is blocked;
Horizontal direction(Kg)
30
Vertical direction(Kg)
Please use "xx-Z" model for vertical load, refer to PAxx-Z series for details
Inverted direction (Kg)
15
Minimum Incremental Motion(um)
≤2
