MJ Series High Load Lab Jack
MJ Series High Load Lab Jack
MJ series Lab Jack is special designed for long travel range and high load occasions in Z axis. The main body is constructed by high hardness aluminum alloy. The surface has been treated with black anode oxidation, a good option for dark environment application.
Features:
•Shear lifting mechanical structure, large stroke, strong load capacity
•Main body material is hard aluminum alloy, the surface with oxidation black treatment, good durability, low reflectivity
•Fine lead screw drive, easy to use
•Multiple specifications, good compatibility, high cost performance
Show Filters:
Naming Rules:
Selection Table
| Model | MJ60 | MJ120 | MJ240 |
| Travel range(mm) | 60 | 120 | 240 |
| Stage surface height range(mm) | 60~120 | 110~230 | 110~350 |
| Stage surface size(mm) | 120×80 | 250×150 | 400×150 |
| Drive type | Fine lead screw，φ8×1 | Two-way fine lead screw，φ12×1.75 | Two-way fine lead screw，φ12×1.75 |
| Main body material and surface | Black anodized aluminum alloy | Black anodized aluminum alloy | Black anodized aluminum alloy |
| Load capacity(Kg) | 10 | 30 | 40 |
| Weight(Kg) | 1.1 | 4.5 | 8.7 |
